Voltage sensor HVS25 Rated input ±5mA Rated output 2.5V±0.625V / 1.65V±0.625V Supply voltage(±5%) +5V/+3.3V

PowerUC

Shipping calculated at checkout.

Model：HVS25

Detect DC,AC and puls e current , high insulation between primary side and the vice side circuit.

Technical index:

Flame resistance：UL94-V0

Operating temperature：-10～+70℃

Storage temperature：-25～+70℃

Dielectric strength：3KV 50Hz 1min

Electric parameters:
